The power source of the hydraulic hammer is the pressure provided by excavators, loaders or pumping stations. It can break the stones and rocks more effectively and improve the work efficiency. The principle of selecting hydraulic hammer is to select the most suitable hydraulic hammer according to the type of excavator and the working environment
Product Description
Product Description
|
|
Company | DEHN400 | DEHN450 | DEHN530 | DEHN600 | DEHN680 | DEHN750 | DEHN850 | DEHN1000 | DEHN1250 | DEHN1350 | DEHN1400 | DEHN1550 | DEHN1650 | DEHN1750 |
|
Host weight (triangular / straight / silent) |
kg | 70/75/102 | 95/95/126 | 138/138/152 | 180/180/224 | 263/263/299 | 334/335/375 | 559/569/589 | 761/866/861 | 1277/1308/1371 |
1653 /1847/1510 |
1774/ 2059/1866 |
2577/ 2745/2968 |
2751/ 3156/2916 |
3905/ 4057/3902 |
|
Length (triangular / straight / silent) |
mm |
910/ 1086/1190 |
1090/ 1235/1331 |
1178/ 1344/1417 |
1239/ 1460/1472 |
1375/ 1684/1660 |
1515/ 1706/1712 |
1735/ 2120/2074 |
1994/ 2387/2354 |
2286/ 2673/2578 |
2423/ 2900/2847 |
2480/ 2866/2793 |
2776/ 3102/3075 |
2820/ 3285/3337 |
3184/ 3812/3723 |
|
Working flow |
1iter/min | 15-25 | 20-30 | 25-50 | 30-60 | 40-70 | 50-90 | 60-100 | 80-110 | 90-120 | 130-170 | 120-180 | 180-240 | 200-260 | 200-260 |
| Hydraulic oil pressure | kg/cm2 | 160 | 160 | 160 | 160 | 170 | 170 | 190 | 190 | 190 | 210 | 210 | 230 | 240 | 240 |
| working pressure | kg/cm2 | 90-120 | 90-120 | 90-120 | 100-130 | 110-140 | 120-170 | 127-147 | 150-170 | 150-170 | 160-185 | 160-185 | 170-200 | 160-180 | 180-200 |
| beat frequency | bpm | 800-1400 | 700-1200 | 600-1000 | 500-1000 | 500-900 | 400-800 | 400-800 | 400-650 | 350-650 | 400-165 | 350-500 | 300-450 | 250-400 | 200-350 |
| Tool diameter | mm | ￠40 | ￠45 | ￠53 | ￠60 | ￠68 | ￠75 | ￠85 | ￠100 | ￠125 | ￠135 | ￠140 | ￠1550 | ￠162 | ￠1750 |
| tube diameter | inch | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 1 | 1 | 1 | 5/4 | 5/4 |
| back head pressure | kg/cm2 | 16 | 16 | 16 | 16 | 16 | 16±0.5 | 16±0.5 | 16±0.5 | 15-18 | 16±0.5 | 16±0.5 | 16±0.5 | 16±0.5 | 16±0.5 |
| Accumulator pressure | kg/cm2 | / | / | / | / | / | / | / | / | / | 60 | 60 | 60 | 60 | 60 |
| Matching vehicle weight | ton | 0.8-2.5 | 1.2-3.0 | 2.5-4.5 | 3-5.5 | 4-7 | 6-9 | 7-14 | 10-15 | 15-18 | 18-25 | 18-26 | 27-36 | 30-40 | 35-40 |
| Matching bucket capacity | m3 | 0.07 | 0.03-0.1 | 0.06-0.2 | 0.06-0.2 | 0.15-0.25 | 0.2-0.4 | 04-0.6 | 0.5-0.6 | 0.4-0.6 | 0.6-1.0 | 0.9-1.2 | 1.0-1.4 | 1.6-2.2 | 1.6-2.2 |
|
Main valve type |
internal | internal | internal | internal | internal | internal | internal | internal | internal | internal | internal | internal | internal |
internal |
Company Profile
DEHN brand has been approved CE certificate and 4 product patents since 2010. By using the piston recoil energy, to increase performance without additional hydraulic flow input, DEHN rock breakers could achieve optimum performance at low cost, in addition to the SIMPLE body design, with only 2 moving parts, leading to lowest maintenance and repairing cost, which eventually makes your investment best valued!
FAQ
1.Is that the main body color customized?
Sure ,but we recommend you yellow, blue and orange.
2. How many days for the delivery time ?
It is about 3-7 working days after the order confirmation.
3. What kind of payments you accept?
Now we accept T/T, L/C or Western Union, other terms also could be negotiated,
4. Are you able to manufacturing products according to customer's design?
Sure, we have made many special orders from abroad since 2010.So we have enough ability to deal with any cases. OEM certificate is available to provided .
5.What's your advantages in the machinery manufacturing industry?
Fast delivery time ,High quality products, Best customer service ,Adopting the latest production technology.
6. Are you sure that your product will fit my excavator?
Our chisel can be adapted to different excavators. Show me your model number, and we would find you best match products.
7. How about the packing of the goods?
We follow the standard export package, wood cases, or as customers' demands
8. How about the packing of the goods?
Standard export package, wood cases, or as customers' demands.
